Overview
A vacuum mixing tank, also known as a vacuum mixer, is a device used in various industries, such as pharmaceuticals, cosmetics, and food processing, to mix and blend different ingredients under vacuum conditions. The vacuum environment helps prevent the formation of air bubbles and enhances the efficiency of mixing. The working process of a vacuum mixing tank typically involves the following steps:
Preparation: The tank is cleaned and sterilized to ensure it is free from any contaminants. The required ingredients, such as powders, liquids, or semi-solids, are measured and added to the tank according to the desired recipe or formulation.
Sealing: Once the ingredients are added, the tank is sealed to create an airtight environment. This is necessary to establish and maintain a vacuum during the mixing process. The tank is equipped with a lid or cover that can be securely closed.
Evacuation: A vacuum pump is used to evacuate the air from the tank. The pump removes the air, reducing the pressure inside the tank. As the pressure decreases, any air bubbles trapped in the ingredients rise to the surface and are expelled.
Mixing: After the desired vacuum level is achieved, the mixing process begins. Agitators, such as blades or impellers, are used to blend the ingredients thoroughly. These agitators can rotate or move in specific patterns to ensure even distribution and efficient mixing. The speed and duration of mixing can vary depending on the requirements of the product being processed.
Monitoring: During the mixing process, various parameters such as temperature, pressure, and mixing speed are monitored to ensure optimal conditions are maintained. This helps to control the quality and consistency of the final product.
Addition of additional ingredients (optional): In some cases, additional ingredients or additives may need to be introduced during the mixing process. This can be done through ports or openings in the tank, allowing for continuous or batch-wise addition.
Degassing (optional): If the mixture contains volatile substances or gases that need to be removed, a degassing step can be performed. This involves further reducing the pressure inside the tank to encourage the release of any trapped gases or volatile compounds.
Completion and discharge: Once the mixing process is complete, the vacuum is released, and the tank is opened. The mixed product can be discharged from the tank for further processing, packaging, or storage.
