Overview
Stainless steel jacket Mixing tank with cone head could be used in a variety of industries, including food, beverage, pharmacy, wine, and alcohol. Blended foods, such as honey, milk, beverages, medicines, chemicals, cosmetics, etc., can be mixed uniformly with uniform speed and electric heaters. The inside surface finish of our tank is Mirror polished, Ra<0.4um. Welding seams are polished to a smooth finish.
Stainless steel mixing tanks can be equipped with various types of agitators: impellers, anchors, turbines, high shear mixers, and magnetic mixers. Mixing tanks can be made with or without jackets. It is made of stainless steel 304 or 316, has an adjustable speed, and is made from stainless steel 304 or 316.
Mixing tanks can be made with or without jackets. There are three types of jackets: full jackets, dimple jackets, and heating coils. There are two types of heating and cooling: steam heating and electric heating. It is also designed to work in Cip or Sip conditions.
Characteristics
1. Made of single layer, two layers or three layers stainless steel structure;
2. Materials are all sanitary stainless steel SUS304/316L;
3. Humanized structure design and easy to operate;
4. interior wall adopts arc for transition to ensure no dead corner when cleaning.
Accessory
1. Quick open manway
2. Various types of CIP cleaning system
3. Sanitary ventilation hood to defend against flies and insects
4. Adjustable triangular bracket
5. Dismountable inlet unit
6. removable legs, with wheels
7. Thermometer (Optional)
8. Ladder (Optional)
9. Liquid level meter and level controller (Optional)
10. Anti-vortex plate
