Stirring Tank with Weighing Module
A stirring tank equipped with a weighing module is an automated weighing solution widely used in industries such as chemicals, pharmaceuticals, and food processing. Its core function is to monitor material weight in real time through high-precision sensors, enabling accurate batching and process control. Below are the key features and applications:
1. Core Features
High-Precision Measurement
Utilizes advanced sensing technology, with some models achieving milligram-level accuracy (e.g., ±0.03% error), suitable for fine chemical or pharmaceutical formulations.
Built-in temperature compensation ensures stability in working environments ranging from -20°C to 150°C.
Modular Design
Offers fixed, semi-floating, and fully floating top plate structures to eliminate weighing errors caused by thermal expansion/contraction of the tank.
Stainless steel (304/316L) construction enhances corrosion resistance for acid/alkali environments.
Automation Integration
Compatible with PLC, DCS, and other control systems for automated functions such as:Start/stop stirring based on weight thresholds
Precise material dosing
Alarm triggering for over/underweight conditions
2. Typical Applications
Chemical Reactors
Ensures ±0.1% accuracy in raw material dosing for polymerization reactions, maintaining product molecular weight consistency.
Food & Pharmaceutical Mixing
Monitors real-time weight changes during blending, optimizing process parameters in conjunction with temperature data.
Cement/Feed Production
Weighs powdered materials dynamically, with explosion-proof modules available for dust-heavy environments.
3. Selection Guidelines
Load Capacity Matching
Must satisfy:
(Tank Weight + Max Material Weight) × 70% ≤ Sensor Rated Load × Number of Sensors
to prevent overload.
Environmental Adaptability
Corrosive media: Choose stainless steel-sealed models.
Explosive atmospheres: Require certified explosion-proof modules (e.g., Ex d IIC T6).
