WENZHOU LENO MACHINERY CO.,LTD

Bright beer tank is Dished head and 60degree cone bottom CO2 blow-off arm with butterfly valve Sanitary top mounted pressure manway CIP arm with 360° coverage CIP spraying ball PT100, solenoid valve, single tank single control Fermentation heat exchanger area: 2.8㎡

Content gauge (Stailess stee shell and glass tube with liquid level valve) Exterior welding seams brushed sand belt, welding points to be acid passivated. heavy duty stainless steel legs with leveling footpads

All inwall polishing, acid picking and passivation.

DESCRIPTION:

Tank body structure :provided with special sampling valve and discharging valve for fermenting tank, as standard temperature PH, and DO sensor vents.Tank cover structure:1 standard foam pole socket ,1 view lamp and sight glass vent,3 universal material adding vents, 1 vaccination vent, 1 air vent.Surface treatment. stainless steel interior and exterior mirror polishing with polishing fineness of Ra0.4 .

Configuration of Tank
